Transfers shear forces for top plate-to-rim joist or blocking connections. Nail holes are spaced to prevent wood splitting for single and double top plate applications. May be installed over plywood...
Transfers shear forces for top plate-to-rim joist or blocking connections. Nail holes are spaced to prevent wood splitting for single and double top plate applications. May be installed over plywood sheathing. 20-gauge galvanized steel. Also available with ZMAX coating. No. LTP4: Size: 3 In. W x 4 1/4 In. L. Material: Galvanized Steel Gauge: 20 ga Finish: Galvanized Number of Holes: 12 Install With: 8d x 1-1/2 In. nails Pkg Qty: 1
Transfers shear forces for top plate-to-rim joist or blocking connections. Nail holes are spaced to prevent wood splitting for single and double top plate applications. May be installed over plywood sheathing. 20-gauge galvanized steel. Also available with ZMAX coating. No. LTP4Z: Size: 3 In. W. x 4-1/4 In. H. Material: Galvanzied Steel Gauge: 20 ga Finish: Z-Max Number of Holes: 12 Install With: 8d x 1-1/2 In. nails Pkg Qty: 1 No. LTP4: Size: 3 In. W x 4 1/4 In. L. Material: Galvanized Steel...
The LCE4's universal design provides high-capacity while eliminating the need for rights and lefts. For use with 4x or 6x lumber. Install in pairs. Dimension: 5-3/8" long. Use 14-16d galvanized...
The LCE4's universal design provides high-capacity while eliminating the need for rights and lefts. For use with 4x or 6x lumber. Install in pairs. Dimension: 5-3/8" long. Use 14-16d galvanized fasteners in beam and 10-16d galvanized fasteners in post. 20-gauge ZMAX galvanized steel. No. LCE4Z: Size: 4 In. x 4 In. Gauge: 20 ga Finish: Z-Max Material: Steel Dimensions: 5-3/8" L Type: End Install With: 14-16d galvanized fasteners in beam Pkg Qty: 1
The Simpson Strong-Tie LTT is a solution for resisting tension loads when used to attach wood to concrete or masonry walls. This light tension tie is designed for horizontal purlin applications and...
The Simpson Strong-Tie LTT is a solution for resisting tension loads when used to attach wood to concrete or masonry walls. This light tension tie is designed for horizontal purlin applications and may also be used for vertical holdown applications. For LTT tension tie applications with unreinforced concrete masonry 3/4-in. post-installed anchor bolts are commonly used. The LTTP2 model for wood joist attachments features an extruded anchor bolt hole to accommodate 1/2-in. 5/8-in. and 3/4-in....
Simpson Strong-Tie LSSJ Adjustable Steel Jack Hanger
Designed for use on the edge of 2x members with a nailing pattern that reduces the potential for splitting. They can be used where plates or soles are cut at wall intersections and as ridge ties....
Designed for use on the edge of 2x members with a nailing pattern that reduces the potential for splitting. They can be used where plates or soles are cut at wall intersections and as ridge ties. Galvanized steel. No. LSTA9: Size: 1-1/4 In. W. x 9 In. L Material: Steel Gauge: 20 ga Finish: Galvanized Pkg Qty: 1 No. LSTA12: Size: 1-1/4 In. x 12 In. Material: Steel Gauge: 20 ga Finish: Galvanized Pkg Qty: 1 No. LSTA18: Size: 1-1/4 In. W. x 18 In. L Material: Steel Gauge: 20 ga Finish: Galvanized...
Simpson Strong-Tie LTS Twist Strap
The LTS provides a tension connection between two members resisting light to medium uplift loads at the rafter or heel of a truss. These economical light twist straps have a 2-in. bend section that...
The LTS provides a tension connection between two members resisting light to medium uplift loads at the rafter or heel of a truss. These economical light twist straps have a 2-in. bend section that reduces interference at the transition points between the two members. The LTS is engineered so the straps do not need to be wrapped over the truss to achieve the allowable load. No. LTS18: Size: 1-1/4 In. x 18 In. Material: Steel Gauge: 18 Ga. Finish: Galvanized Install With: 12-10d or 12-10d x 1/2...
Value engineered for strength and economy. Speed prongs included for placement of hanger during installation. 20-gauge galvanized steel. No. LU24: Material: Steel Gauge: 20 Joist Size: 2 In. x 4 In....
Value engineered for strength and economy. Speed prongs included for placement of hanger during installation. 20-gauge galvanized steel. No. LU24: Material: Steel Gauge: 20 Joist Size: 2 In. x 4 In. Type: Face Mount Finish: Galvanized Install With: 4-10d/4-16d Face & 6-10dx1-1/2 Joist Width (In.): 1.5625 Height (In.): 3.125 Base (In.): 1.5 Pkg Qty: 1 No. LU26: Material: Steel Gauge: 20 Joist Size: 2 In. x 6 In. Type: Face Mount Finish: Galvanized Install With: 4-10d/4-16d Face & 6-10dx1-1/2...
Value engineered for strength and economy. Speed prongs included for placement of hanger during installation. 20-gauge galvanized steel. No. LU26: Material: Steel Gauge: 20 Joist Size: 2 In. x 6 In....
Value engineered for strength and economy. Speed prongs included for placement of hanger during installation. 20-gauge galvanized steel. No. LU26: Material: Steel Gauge: 20 Joist Size: 2 In. x 6 In. Type: Face Mount Finish: Galvanized Install With: 4-10d/4-16d Face & 6-10dx1-1/2 Joist Width (In.): 1.5625 Height (In.): 4.75 Base (In.): 1.5 Pkg Qty: 1 No. LU28: Material: Steel Gauge: 20 Joist Size: 2 In. x 8 In. Type: Face Mount Finish: Galvanized Install With: 4-10d/4-16d Face & 6-10dx1-1/2...
Concealed flange hanger available for 2x6 2x8 2x10 and 2x12 lumber. Ideal for end of ledger/header or post conditions. Also provides cleaner lines for exposed conditions such as overhead decks....
Concealed flange hanger available for 2x6 2x8 2x10 and 2x12 lumber. Ideal for end of ledger/header or post conditions. Also provides cleaner lines for exposed conditions such as overhead decks. Value engineered for strength and economy as well as installation ease. 18-gauge galvanized ZMAX steel. No. LUC26Z: Material: Steel Gauge: 18 Joist Size: 2 In. x 6 In. and 2 In. x 8 In. Type: Concealed Flange Finish: ZMAX Install With: 6-10d header 4-10d joist Width (In.): 1.5625 Height (In.): 4.75 Base...
This hanger features patented double shear nailing which distributes the load through 2 points on each joist nail for greater strength. It also allows for the use of fewer nails faster installation...
This hanger features patented double shear nailing which distributes the load through 2 points on each joist nail for greater strength. It also allows for the use of fewer nails faster installation and the use of common nails for all connections. 18-gauge galvanized steel. Some double shear joist hangers are available in ZMAX coating. No. LUS24: Material: Steel Gauge: 18 Joist Size: 2 In. x 4 In. Type: Double Shear Finish: Galvanized Install With: 4-10d Nails on header 2-10d Nails Joist Width...
